FANUC DR-3iB/6 STAINLESS stainless high-speed 4-axis delta robot with R-30iB Plus controller

FANUC DR-3iB/6 STAINLESS with R-30iB Plus controller is a stainless high-speed 4-axis delta robot from the DR-3 family. It has a rated wrist payload of 6 kg and a maximum working reach of 1200 mm.

The DR-3 family is part of FANUC's range of protected parallel-link delta robots. It is intended for food handling, washdown packaging and high-speed pick-and-place. The mechanical configuration of this model is identified as Stainless, allowing the robot to be selected for a clearly defined combination of payload, reach and installation layout.

This model uses 4 controlled axes and has a published positioning repeatability of ±0.03 mm. Its stated mounting arrangement is ceiling. Final payload capacity must be checked against the complete tool, workpiece, center-of-gravity and inertia data rather than the nominal wrist payload alone.

Controller compatibility: the model is listed for the R-30iB Plus control generation. For CMS classification, all supported cabinet forms are consolidated under the single controller name R-30iB Plus. Electrical supply, cabinet size, safety options, fieldbus interfaces, software packages and regional availability still have to be confirmed for the exact robot order code.

Typical applications

• advanced manufacturing
• assembly of parts
• handling of parts
• loading and unloading of parts

For a Eurobots project, FANUC DR-3iB/6 STAINLESS can be evaluated for new automation, controller-standardization studies, replacement projects, process trials and complete robotic cells. Engineering approval should be based on the exact mechanical-unit specification, load diagram, mounting orientation, environmental option and controller software release.
