KUKA KL250-3 Linear track

More workspace. Higher productivity.

The KL 250-3 linear unit allows robots to move dynamically along the production line, dramatically increasing coverage without sacrificing accuracy. This makes it an ideal solution for linking processes, optimizing cell layouts, and reducing cycle times in medium-payload applications.

As part of KUKA’s modular linear unit range, the KL 250-3 is available in standard and covered (CV) variants, offering additional protection in demanding industrial environments.

Key Benefits

High positional accuracy
Up to four robots can operate on a single KL 250-3 axis. Multiple programmable positions along the travel length allow precise adaptation to complex production layouts.

Flexible automation design
With travel lengths of up to 30 meters, the KL 250-3 extends the robot’s reach far beyond its nominal workspace, enabling efficient servicing of multiple machines or workstations.

Versatile installation
Available in floor and ceiling-mounted configurations, supporting a wide range of industrial cell designs.

Reliable performance
Designed for continuous industrial operation, the KL 250-3 offers a balanced combination of speed, load capacity, and repeatability, ensuring stable performance in demanding applications.

Productivity enhancement
Optional additional carriages—driven or non-driven—allow transport of tools or workpieces along the axis, further reducing idle time and optimizing process flow.
