Kawasaki BA006L

Awaiting more stock

Kawasaki BA series more powerful robots for arc welding providing a high level of speed, rigidity, compact structure, reliability and ease of use. The articulated robot BA006L with 6 axes, maximum reach of 2,036 mm and payload capacity of 6 kg is characterized by its hollow wrist that facilitates the handling of the cables and hoses around the torch for greater safety and reliability.

Main specifications

Maximum Load of Robot: 6 kg
Number of axis: 6
Maximum horizontal reach: 2036 mm
Repeatability: ±0.08 mm
Controller: E01

Motion range (°)

Axis JT1: ±165°
Axis JT2: +150°/−90°
Axis JT3: +90°/−175°
Axis JT4: ±180°
Axis JT5: ±135°
Axis JT6: ±360°

Maximum speed (°/s)

Axis JT1: 210°/s
Axis JT2: 210°/s
Axis JT3: 220°/s
Axis JT4: 430°/s
Axis JT5: 430°/s
Axis JT6: 650°/s


Robot applications

Arc welding
